MAX Series (High Performance Bandsaw)
Horizontal Band Saws
Standard Equipment:
wireless remote control
Variable blade speed controlled by inverter
Hydraulic blade tension
Power driven wire brush
Real-time sensing device
Saw frame balancing system
Automatic chip conveyor
Schneider low voltage Electric
High precision servo feed
Intelligent self-adapting sawing system
Capacity (inch)
15.7"
15.7" x 15.7"
Blade size (inch) 1.6" x 0.05"
Blade speed (fpm) 65.6-262.5 fpm
Blade drive motor (hp) 10.1
Hyd. pump motor (hp) 2.99
Coolant pump motor (hp) 0.18
Hyd. oil (gallon) 39.6
Cutting liquid (gallon) 105.6
Machine size (LxWxH) (inch) 165”X 88”X 76"
Machine Weight (LBS) ≈ 13227
