Standard Equipment:
Automatic chip conveyor
Hydraulic blade tension
Variable blade speed controlled by inverter Base adjustment
Schneider low voltage Electric
CE certified limit switches
CE certified control buttons
Intelligent self-adapting sawing system
Optional Equipment:
Servo feeding Roller-type bed
Capacity (inch) 50.0", 50.0" x 50.0"
Blade size (inch) 542.1" x 2.6" x 0.06"
Blade speed (fpm) 65.6-262.5
Blade drive motor (hp) 29.9
Hyd. pump motor (hp) 5.0
Coolant pump motor (hp) 0.24
Hyd. oil (gallon) 26.4
Cutting liquid (gallon) 39.6
Machine size (LxWxH) (inch) 275" x 197" x 142"
Machine Weight (LBS) ≈ 48502
Direct-Drive Gearbox Gearbox
